Prepínač a switch Aruba 2530 8 PoE+ Switch

J9780A
Přehled - Switch s managementem - Routing/Switching: Layer 2 Only - 8x 10/100 PoE RJ45 portů + 2x Combo porty + 1x Dual-personality (RJ-45 nebo USB micro-B) serial console port - PoE budget: 67W, Power Over Ethernet Plus (IEEE 802.3at) - WDRR, ACLs, IPv4/IPv6 host support - Virtual stacking - single IP address management až pro 16 switchů - Šetří více energie: 802.3az a Idle port (Nižší spotřeba při neaktivitě portu) - Tichý chod - regulace rychlosti větráků - Montáž do 19“ racku, montáž na zeď -
Doživotní záruka: Záruka 99 let! -
Oprava výměnou následující pracovní den! -
Nově:
3-letá 24x7 Softwarová podpora v ceně!
Charakteristika řady 2530
Quality of Service (QoS) Traffic prioritization (IEEE 802.1p), Simplified QoS configuration, Port-based, VLAN-based, Class of Service (CoS), Rate limiting, Layer 4 prioritization, Flow control
Management Choice of management interfaces, Web graphical user interface (GUI), Command-line (CLI), Simple Network Management Protocol (SNMPv1/v2c/v3), Virtual stacking, sFlow (RFC 3176), IEEE 802.1AB Link Layer Discovery Protocol (LLDP), Logging, Port mirroring , RMON (remote monitoring), Find-Fix-Inform, Friendly port names, Dual flash images, Multiple configuration files, Front-panel LEDs, Locator LED, Per-port LEDs, Power and fault LEDs
Connectivity IPv6, IPv6 host, Dual stack (IPv4/IPv6), MLD snooping, IEEE 802.3af Power over Ethernet (PoE), IEEE 802.3at Power over Ethernet Plus, Auto-MDIX, Pre-standard PoE support, Small Form-Factor Pluggable (SFP) slots, Dual-personality (RJ-45 or USB micro-B) serial console port
Layer 2 switching VLANs, Jumbo packet support, 16K MAC address table, GARP VLAN Registration Protocol
Security Access control lists (ACLs), Source-port filtering, RADIUS/TACACS+, Secure Sockets Layer (SSL), Port security, MAC address lockout, Multiple user authentication methods, IEEE 802.1X, Web-based authentication, MAC-based authentication, Secure Shell (SSHv2) (client and server), Secure Shell, STP BPDU port protection, STP Root Guard, Secure management access, Custom banner, Secure FTP, Protected ports CLI, Authentication flexibility, Multiple IEEE 802.1X users per port, Concurrent IEEE 802.1X and Web or MAC authentication schemes per port, Switch management logon security
Convergence LLDP-MED (Media Endpoint Discovery), IP multicast (data-driven IGMP), IEEE 802.1AB Link Layer Discovery Protocol (LLDP), PoE and PoE+ allocations, Voice VLAN, IP multicast (data-driven IGMPv3)
Resiliency and high availability Port trunking and link aggregation, Trunking, IEEE 802.3ad Link Aggregation Protocol (LACP), IEEE 802.1s Multiple Spanning Tree
Product architecture Energy-efficient design, IEEE 802.3az, Port low power mode, Fans, Port LEDs, Switch on a chip
Flexibility Flexible mounting, Rackable, Wall mountable, Surface mountable, Quiet operation
Warranty and support Lifetime warranty, Electronic and telephone support, Software releases
Technická specifikace
Porty 8 RJ-45 autosensing 10/100 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3at PoE+) Media Type: Auto-MDIX Duplex: half or full, 2 dual-personality ports each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type 10Base-T, IEEE 802.3u Type 100Base-Tx, IEEE 802.3ab 1000Base-T Gigabit Ethernet) or as a SFP slot (for use with SFP transceivers) ports, 1 dual-personality (RJ-45 or USB micro-B) serial console port
Rámování Mounts in an EIA-standard 19-inch telco rack or equipment cabinet (rack-mounting kit available), horizontal surface mounting, wall mounting
Provedení 1U height
Paměť a procesor Processor : ARM9E @ 800 MHz, 128 MB flash, packet buffer size: 1.5 MB dynamically allocated, 256 MB DDR3 DIMM
Čekací doba 100 Mb Latency: < 1.3 µs (LIFO 64-byte packets), 1000 Mb Latency: < 2.3 µs (LIFO 64-byte packets)
Datový tok up to 4.1 million pps (64-byte packets)
Funkce správy IMC - Intelligent Management Center, command-line interface, Web browser, configuration menu, out-of-band management (serial RS-232C or Micro USB), IEEE 802.3 Ethernet MIB, Repeater MIB, Ethernet Interface MIB
Přepínací kapacita 5.6 Gbps
Obecné protokoly IEEE 802.1D MAC Bridges, IEEE 802.1p Priority, IEEE 802.1Q VLANs, IEEE 802.1s Multiple Spanning Trees, IEEE 802.1w Rapid Reconfiguration of Spanning Tree, IEEE 802.3 Type 10BASE-T, IEEE 802.3ab 1000BASE-T, IEEE 802.3ad Link Aggregation Control Protocol (LACP), IEEE 802.3af Power over Ethernet, IEEE 802.3at Power over Ethernet Plus, IEEE 802.3az Energy Efficient Ethernet, IEEE 802.3x Flow Control, RFC 768 UDP, RFC 783 TFTP Protocol (revision 2), RFC 792 ICMP, RFC 793 TCP, RFC 826 ARP, RFC 854 TELNET, RFC 868 Time Protocol, RFC 951 BOOTP, RFC 1350 TFTP Protocol (revision 2), RFC 1542 BOOTP Extensions, RFC 2030 Simple Network Time Protocol (SNTP) v4, RFC 2131 DHCP
IPv6 RFC 1981 IPv6 Path MTU Discovery, RFC 2460 IPv6 Specification, RFC 2925 Remote Operations MIB (Ping only), RFC 3315 DHCPv6 (client only), RFC 3513 IPv6 Addressing Architecture, RFC 3596 DNS Extension for IPv6, RFC 4022 MIB for TCP, RFC 4113 MIB for UDP, RFC 4251 SSHv6 Architecture, RFC 4252 SSHv6 Authentication, RFC 4252 SSHv6 Transport Layer, RFC 4254 SSHv6 Connection, RFC 4293 MIB for IP, RFC 4419 Key Exchange for SSH, RFC 4443 ICMPv6, RFC 4861 IPv6 Neighbor Discovery, RFC 4862 IPv6 Stateless Address Auto-configuration
IP Multicast RFC 3376 IGMPv3 (host joins only)
Správa sítě IEEE 802.1AB Link Layer Discovery Protocol (LLDP), RFC 1098 A Simple Network Management Protocol (SNMP), RFC 2819 Four groups of RMON: 1 (statistics), 2 (history), 3 (alarm) and 9 (events), ANSI/TIA-1057 LLDP Media Endpoint Discovery (LLDP-MED), SNMPv1/v2c/v3
Spotřeba energie 76.7 W (maximum), 5.8 W (standby)
Zdroj napájení - PoE 67 W
